NC servo tape machine
To get more details about our Carton box Smart equipments, pls visit here
Function
Be suitable for corrugated board production, tape is applied to the crimping part. Improve the strength of the cardboard and solve the problem of damage in the carton bundling.
Feature
Compared with the traditional manual adjustment of the tape machine, the machine has the advantages of quick order change, accurate positioning, high work efficiency, safety and reliability.
l The highlight: synchronously track the position of scoring line, has manual adjustment function as well. Work together with Slitter scorer and align the same position of the scoring line. Two sets of strips can be installed at one time, automatically detect the remaining tape and automatically switch the strips.
Parameters Tables
|
Item |
Description |
|
Model |
NCJD-2200/2500/2800 |
|
Strip Configuration |
the width depends on customer, common 35mm |
|
Max gap of tape paste |
Customization |
|
Min.gap of tape paste |
160mm |
|
Order change speed |
3s |
|
Host computer |
High quality MCGS Touch screen |
|
PLC |
FATEK PLC |
|
Adjustment motor |
TECO Servo motor 0.45KW*6 |
| Servo controller |
TECO Servo series |
|
Low voltage |
Schneider |
|
Transmission |
Precision gear and rack |
|
Size |
3580×800×1710mm |
|
Power |
3KW |
